British ASTA certified 3 prong IEC C13 power cord receptacle

British ASTA certified 3 prong IEC C13 power cord receptacle
Product name : British ASTA certified 3 prong IEC C13 power cord receptacle
Item : D09/2QT3
Details :
British ASTA certified 3 prong IEC C13 power cord receptacle.  Built to the IEC 60320-C13 standard for use in the UK.  Rated up to 10A 250V

Specifications

Items
Details
Connector Standard IEC 60320 C13
Maximum Current rating 10A
Maximum Voltage 250V
Number of Poles and Wires 2 poles, 3 wires
Available Wire Thickness 1.5mm² through 0.75mm²
Outer Mold Material 50P PVC
Blade Material Brass
Flamability Rating UL 94V-0
color black is standard but any color available
Temperature Rating minus 40C though plus 75C
Approvals ASTA license# 785, ENEC certificate# 40029577 and many others
Environmental Certifications RoHS, REACH
Testing Hi-Pot (Dielectric Withstanding Voltage), Polarity (pinout) and Continuity
