IEC C7 power cord receptacle with UL and CSA certification

IEC C7 power cord receptacle with UL and CSA certification
Product name : IEC C7 power cord receptacle with UL and CSA certification
Item : QT2
Details :

IEC C7 power cord receptacle with UL and CSA certification.  Built to the IEC 60320-C7 standard.  Rated up to 10A 125V for use in North and South America.  Our IEC C7 power cord receptacles are fully molded with a low profile, ergonomic, molded design and RoHS and REACH compliant.

Specifications

Items
Details
Connector Standard IEC 60320-C7
Maximum Current rating 15A
Maximum Voltage 125V
Number of Poles and Wires 2 poles, 2 wires
Available Wire Thickness 18AWG
Outer Mold Material 35P PVC
Blade Material Brass
Flamability Rating UL 94V-0
color black is standard but any color available
Temperature Rating minus 40C though plus 75C
Approvals cUL file
Environmental Certifications RoHS, REACH
Testing Hi-Pot (Dielectric Withstanding Voltage), Polarity (pinout) and Continuity

Available Opposite End Connectors

Standard
Part Number
NEMA 1-15P non-polarized 2 pin plug
NEMA 1-15P

NEMA 1-15P
low profile angled NEMA 1-15P


NEMA 1-15P non-polarized down angle low profile 2 pin plug
(NEMA 1-15P)

NEMA 1-15P non-polarized right angle low profile 2 pin plug
 (NEMA 1-15P)


IEC C8 2 pin plug
IEC C8



Available Wire Styles

Gauge/ # Conductors Cord Type Electrical Rating (Amps/Volts)
18/2 SPT-1, SPT-1W, SPT-2, SPT-2W, NISPT-2, SVT, SJT, NISPT-1 10/125 or 2.5/250
