Korea three prong right angle power cord plug with KTL |
|
| Product name : Korea three prong right angle power cord plug with KTL |
| Item : K03 |
| Details : |
KSC8305 Korea three prong right angle power cord plug with KTL (Korea Testing Laboratory) certification. Rated up to 16A 250V. Built to the Korea KSC8305 and K60884-1 power cord plug standard. Our Korean power cord products are fully molded with a low profile ergonomic design and RoHS and REACH compliant.
Specifications
Items
Details
| Connector Standard |
Korea KSC 8305 3P right angle plug (same as Europe CEE7/7 standard Euro 3P plug) |
| Maximum Current rating |
16A |
| Maximum Voltage |
250V |
| Number of Poles and Wires |
2 poles, 3 wires |
| Available Wire Thickness |
1.5mm² through 0.75mm² |
| Outer Mold Material |
50P PVC |
| Blade Material |
Nickel coated Brass |
| Flamability Rating |
UL 94V-0 |
| color |
black is standard but any color available |
| Temperature Rating |
minus 40C though plus 75C |
| Approvals |
Korea KTL certificate# SU04001-1003A , German VDE license# 40005197 and many others |
| Environmental Certifications |
RoHS, REACH |
| Testing |
Hi-Pot (Dielectric Withstanding Voltage), Polarity (pinout) and Continuity |
Available Opposite End Connectors
Standard
Part Number
right angle IEC C13
(IEC C13) Korea
right angle IEC C5
(IEC C5) Korea
Available Wire Styles
| Gauge/ # Conductors |
Cord Type |
Electrical Rating (Amps/Volts) |
| 0.75mm² |
H05VV-F |
10/250 |
| 1.00mm² |
H05VV-F |
10/250 |
| 1.50mm² |
H05VV-F |
16/250 |
|
 |
